1. It adopts a fully automatic feeding rack, no need for manual feeding, turning, and feeding, one person with multiple machines. Reduce labor intensity and save costs.
2. Professional double metal sliding guide, anti-wear, durability and good
3. Fully enclosed clamshell knife mold, easy to change the knife, 360-degree rotation, repeated use, longer service life
4. reinforced gear alloy steel production, standardizing heat treatment, transmission torque
5. Reasonable retaining design makes the size of the blanking more accurate, the weight deviation is smaller, and the section flatness is higher
6. Reasonable design of retaining mechanism to make the size of blanking accurate and easy to adjust
7. The equipment adopts an automatic centering device, cutting round steel of different diameters without adjusting the height of the feeding frame
8. Professional bi-metal sliding guide, good wear resistance, and durability
9. Guide rail lubrication automatic oil pump added, automatic alarm for oil cut
2、Using closed mould,replacing the mould is very convenient ,the mould can be used repeatedly through rotate it,for long service life.
3、The drive gears adopt high quality alloy steel,after heat treatment and lapping finish
4、Professional bimetal sliding guide rail,good resistance to wear and durability
5、Adopted with center automatic lubrication system for guideway to have the good performance for little resistance,little friction,good lubrication and long life etc.oil cut-off automatic alarm
6、Keep-off mechanism design is reasonable,makes the size of blanking exact，small tolerance
7、Using the enclosed gear box, gear gumming lubrication
| LYQ-30 main technical parameters | |
| Model | BCM-30 |
| The max diameter of cutting | 28 |
| The fastest speed of cutting(s/min) | 65 |
| The scope of gauge(mm) | 20-350 |
| Main motor power | 3KW |
| Yes or No the clutch | yes |
| The size of equipment | 360*820*1380 |
| The motor of automatic feeding frame | 0.75KW |
| The feeding speed | 300mm/s |
| The discharging mouth from the ground level | 868mm |
| The size of feeding frame(mm) | 6000*1800*1000 |
| Weight(kg) | 2000 |
| BCM-30 Material allocation table | ||
| Meterial | The max diameter of cutting | remark |
| Round steel | ||
| 20# Q235 | φ36 | If the material is cold rolled condition, the max diameter of shearing reduces by twenty percent |
| 20MN 20Cr | φ34 | |
| 45# 1Cr13 40MN | φ32 | |
| 55# 40Cr 20CrMnTi 2Cr13 | φ22 | |
| 35CrMo 3Cr13 | φ20 | |
| 42CrMo GCr15 60Cr2Mn | φ16 | |
Product Details
CNC lubricating oil pump
The automatic lubrication system consists of CNC lubricating oil pump and oil separator.
to each refueling point, which is convenient and practical, and eliminates the hidden danger of wear caused by lack of oil.
Automatic feeding
