| tem | DHM-1030DT | DHM-2030DT | DHM-3030DT | DHM-4030DT | |
| Processing stroke (stroke can be customized) |
Xaxis | 1000mm | 2000mm | 3000mm | 4000mm |
| Yaxis | 300mm | ||||
| Zaxis | 200mm | ||||
| Spindle | Speed | 1500~24000rpm(Can be configured according to actual demand) | |||
| Taper hole | ER20 | ||||
| Power | 0.55kw~3.0kw(Can be configured according to actual demand) | ||||
| Movement speed |
Xaxis | 30m/min~60m/min | |||
| Yaxis | 25m/min | ||||
| Zaxis | 25m/min | ||||
| Processing capability |
Drilling | 1~20mm | |||
| Tapping | M2-M14 | ||||
| Chamfering | 1~20mm | ||||
| Tool magazine | Manual tool change | ||||
| Repeated positioning accuracy | ±0.02mm | ||||
| Workbench guide | 25mm | ||||
| Pneumatic fixture | 2sets | 4sets | 6sets | 8sets | |
| Programmng mode | CAD file import/computer programming/instructional programming/manual programming | ||||
| System program memory | About 10000 pcs | ||||
| System external signal control | Support | ||||
| Working voltage | AC 220V/50HZ | ||||
| Floor area | 2500mm*1500mm*1700mm | 3500mm*1500mm*1700mm | 4500mm*1500mm*1700mm | 5500mm*1500mm*1700mm | |
| Machine tool weight | About 1000kg | About 1500kg | About 2000kg | About 2500kg | |
