DHD1500 Shaft CNC Deep Hole Drilling Machine

1.There are both single axis processing and multiple axis processing function.

2.The CNC programming automatic processing ensures the good quality such as the spacing of the hole, diameter tolerance, verticality, harshness, etc.

3.It’s a totally different from the traditional processing ways of multiple collections, which extremely improves the production capacity.

4.Adopt Three jaw chuck or self drive cone disc, to provide the most appropriate solutions to users.

5.It can be applied in the processing of biaxial for automobile gearbox,3mm stainless stell deep hole,40 Cr rod deep hole and so on.

DHD1500 Axis CNC deep hole drilling machine
Processing capacity Machine aperture range ∮4~30mm
Maximum drilling depth 1500mm
The maximum length of workpiece 1600mm
Spindle Qty. of spindle 1个
Spindle centerline spacing 200mm
Maximum speed of spindle 4500rpm
Spindle feed speed 100mm/min
Spindle fast moving speed 1000mm/min
Power Spindle motor 7.5kw
Total power 18kw
Cooling system Pressure range of cooling liquid 2~10MPa
Flux range of cooling liquid 0~200L/min
Machine tool Floor area of machine tool(L*W) 5000×2600×2000mm
Weight 10ton
